HCR3-1508 8-head embroidery machine


* Payment based on 72-month term, 10% down payment for well-qualified buyers. Rates subject to change. Pricing reflects standard machine package.

Happy’s HCR3-1508 is the company’s strongest, most productive 8-head machine ever with its advanced, high-speed servo drive.

HappyJapan 8-head embroidery machine

Our strongest, most productive 8-head model

Happy’s HCR3-1508 is the company’s strongest, most productive 8-head machine ever. The servo drive system allows for faster, quieter sewing, and reinforced construction in many key areas for greater durability and more consistent quality over a wide variety of conditions.

HappyJapan HCR3-1508 8-head embroidery machine

Check out these GREAT benefits

Amazing Embroidery On Ball Caps

Easy Maintenance

Easy Touchscreen Control Panel

The strongest and most productive 6-head yet!

Standard Features:

  • Color LCD touchscreen panel
  • Customizable front screen apps
  • USB/LAN ports for direct PC connection
  • Built-in help, auto-error correction
  • Combine designs & text directly onscreen
  • Built-in lettering & stock designs
  • Onboard editing: rotate, scalle, mirror, satin pull compensation, stitch cleanup, lockstitching
  • Import any compatible 3rd-party hoop onscreen for accurate positioning
  • Load, set up additional designs while machine is running

Create professional-quality designs with HappyJapan precision embroidery machines.

Dimensions list:

  • L (length) – 3980mm / 156.7in
  • D1 – 830mm / 33in
  • D2 – 1320mm / 52in
  • H1 – 1510mm / 59.5in
  • H2 – 1740mm / 68.5in
  • Weight: 1070Kg / 2354 lbs
  • Maximum speed: 1100spm tubular / 1000spm caps
  • Maximum embroidery area on tubular/flat goods: 360mm x 450mm (14.2in x 17.7in)
  • Maximum embroidery area on finished ballcaps: 80mm x 360mm (3.1”h x 14.1”w)
  • Power requirements: Single Phase 200-240V, 540W, 60Hz

Included with the machine:

  • Operator’s toolkit
  • HappyLINK, HappyLAN connection software, parts & operator’s manuals
  • Complete tubular hoop set, 2 hoops per head:
    • 16ea. 32cm (12in) square hoops
    • 16ea. 18cm (7.1in) round hoops
    • 16ea. 15cm (5.9in) round hoops
    • 16ea. 12cm (4.7in) round hoops
  • Complete cap sewing kit, including:
    • 16ea. Wide-field cap frames
    • Cap stretcher
    • 8ea. Cap drivers
    • 4ea. Cap sashes
  • Repositionable support table
  • Heavy-duty casters & attachment hardware

Take your embroidery to the next level!

Equip your business with easy-to-use multi-head embroidery machines.

10 Year Warranty on new HappyJapan embroidery machines exclusively through

We’re so confident you’ll love our single-head embroidery machines that we offer a 10-year warranty. We stand firmly behind the resilience and performance of our machines. Join thousands of satisfied customers who trust HappyJapan’s commitment to quality and excellence. Invest in a machine backed by a solid 10-year warranty guarantee today.

Choosing the right embroidery machine is paramount for your success

Without an unreliable single-head embroidery machine, your business could face unpredictable breakdowns, inconsistent stitch quality, and financial loss. This can slow production rates and tarnish your brand’s reputation in a competitive marketplace. Choosing HappyJapan’s single-head embroidery machines equips your business with precision, speed, and reliability. Let us guide you to a future of seamless operations, delighted customers, and unrivaled embroidery excellence.
